Purpose
Used for mixing asbestos and non-asbestos friction materials.
Performance Features
Adopts new high-speed auxiliary mixing blades and scientifically designed mixing barrel with pneumatic discharging, ensuring no dead corners during mixing.
Equipped with a cooling water circulation system, suitable for high-speed mixing of non-asbestos brake pad formula materials, and better ensures the stability of various process ratios.
Technical Specifications
| Design volume of mixing barrel | 300 L |
| Working volume of mixing barrel | 270 L |
| Batch mixing weight | Approx. 50–80 kg |
| Total installed power | 35.5 KW |
| Main motor power | 30 KW |
| Spindle impeller speed | 960 r/min |
| Spindle impeller material | Stainless steel |
| Mixing knife speed | 2880 r/min |
| Mixing knife material | Manganese steel |
| Mixing time | Approx. 4–6 min per batch (adjustable by user according to formula requirements) |
| Net weight | 2000 Kg |
Included Materials
- Complete machine: 1 set
- Electric control cabinet: 1 set
- Operation manual: 1 copy
- Certificate of conformity: 1 copy
