Purpose
For dust recovery and treatment in friction material production lines.
Performance Features
Utilizing the latest domestic electromagnetic pulse technology, it delivers high energy processing capacity and advanced dust cleaning technology, featuring high dust removal efficiency, simple structure, user-friendly operation, and reliable performance.
Technical Parameters
| Item | Details |
| Model | BYMC-64-150 |
| Filter Area | 60 m² |
| Filter Bag Count | 64-150 Bag |
| Specifications | ∮120×2500mm |
| Operating Temperature | 120°C |
| Equipment Pressure | 1200-1500 Pa |
| Dust Removal Efficiency | 99.5% |
| Input Dust Concentration | 15 g/m³ |
| Filter Air Velocity | 1.5 m/min |
| Clean Air Pressure | ≥4 MPa |
| Backdraft Airflow | 12 m³/h |
| Processing Airflow | 10,314-20,638 m³/h |
| Spray Duration | 0.1-0.2s |
| Power | 15-18.5 kW |
| Maximum Dimensions | 1800×1800×5200 mm |
| Weight | Approximately 3.5 tons |
Included Materials
- 1 copy of User Manual.
- 1 copy of Certification.
Note: Configuration or special designs can be customized according to user requirements!
