Introduction
- The gas-liquid supercharged cylinder has a pressing force of 3T, atotal stroke of 50mm, and a pressing stroke of 10mm.
- Modular design,simple structure, strong and durable.
- The conveyor belt uses dual sensors to automatically calculatethe length of the brake pads, and uses a servo motor for precisepositioning to ensure that brake pads of different sizes can beaccurately delivered directly under the pressure head.
- Optional heating component: polyurethane pressure and heatingcomponent can be quickly switched.
- Optional storage mechanism: After workers stack the brake pads onthe belt, the equipment automatically transports the brake pads tothe right side of the press according to the set spacing. (Advantage:One person can operate multiple pressure bonding machines at the same time)
- Equipped with human-computer interaction interface.
Technical Parameters
| Item | Details |
| MODEL | QK-150-YZ-3T |
| Maximum passing width | 150mm |
| Maximum passing height | 45mm |
| Maximum pressing force | 3T |
| Cycle time | 3-4S |
| Total stroke | 50mm |
| Pressing stroke | 10mm |
| Heating power | 450W |
| Total power | 1500W |
| Weight | 400KG |
| Dimensions of Pressing part | L330*W260*H850mm |
| Dimensions of Conveyor | L1300*W260*H120mm |
| Workbench height | 750mm |
| Dimensions of the Machine | L1300*W600*H1500mm |
