Application
Suitable for the out-arc grinding processing of all kinds of the brakes of motorcycle，light trucks and cars.
Performance Characteristics
With the convenient fixture replacement；The clamping fixture axis speed is non-polar adjustable;It adopts the diamond tools to make the operation convenient, safe and reliable, and the texture clear and smooth.
Technical Parameters
| Item | Details |
| Range | Internal diameter: ∮50–150mm External diameter: ∮100–300mm Width: ≤100mm |
| Spindle motor | 4kW / 1440 r/min |
| Spindle grinding wheel | ∮250mm (diamond) |
| Clamping fixture motor | 0.55kW (motor adjustment) |
| Speed | Adjustable |
| Output | ~10,000 pieces/shift |
| Overall dimensions | 1300mm × 650mm × 1200mm |
| Total weight | ~1,200kg |
Random data
- One use specification
- One qualification
Note:You can change the configuration according to user requirements or other special design!
